Monochrome LCD module Graphic type 128X64 dots COG with ST7567 IC FSTN Positive LCD

128x64 COG Graphic LCM Description

SAEF Technology SF-BS12864H-GW is a monochrome graphic type128x64 COG LCD module.

Product Quick Details:
1. LCD Size: Graphic Monochrome LCD Module
2. Resolution: 128x64
3. Viewing Angle: 6:00
4. Outline Dimension: 65x84.4x7.8mm
5. Driver IC: ST7567

6. LCM Interface Type: 4-line SPI
7. Temperature: Top -20°C to +70°C; Tst -30°C to +80°C
8. Touch Panel: Without Touch Panel(Customizable)

Product Features:
1. SF-BS12864H-GW model is built in with ST7567 controller or equivalent IC; it supports 4-line SPI serial interface.

2. This SF-BS12864H-GW graphic Display LCD 128x64 module is 3.3V(typical value) for supply voltage.

3. This 12864 Graphic LCD module is with white LED backlight. SF-BS12864H-GW is FSTN Positive transflective mode.

4. This model graphic LCD display can be operating at temperatures from -20℃ to +70℃; its storage temperatures range from -30℃ to +80℃.

5. This LCD module is originally without touch, but touch panel is customizable.

6. This module is widely used in POS terminal, cash reader, handheld device, mobile food ordering machine, meter and instrument, medical analyzer, etc.

Quality assurance

1.For every piece, we have 3 times 100% test to ensure good quality.

2.The QA manager has been in the LCD industry for more than 14 years. The key manufacturing and QA operators have been in the LCD industry for more than 7-8 years. Our team are all very professional and experienced in the LCD filed to ensure quality for customers.

FAQ:

Q1. Can I have a sample order?

A: Yes, we welcome sample order to test and check quality. Mixed samples of different item numbers are acceptable.

Q2. What about the lead time?

A: For off-shelf products, in-stock samples immediately. 1-1.5 wks for sample remaking. 4-6 wks for mass production. For design-in products, 2-3 days for counter drawing proposal; 2 wks for sample making at drawing approval; 5-6 wks for trial-run/mass production at sample approval.

Q3. Do you have any MOQ limit for sample and production order?

A: Low MOQ. 3-5pcs for sample checking is available. Mass production MOQ is normally 1K/lot. We support qty lower than MP MOQ for trail-run/PP-run order.

Q4. How do you ship the goods and how long does it take to arrive?

A: Ship by DHL, UPS, FedEx or TNT. It takes 5-7 days to arrive. Airline and sea shipping also optional.

Q5. How to proceed an order for LCD module?

A: Firstly let us know your requirements or application.

Secondly We quote according to your requirements or our suggestions.

Thirdly customer confirms the samples and places deposit for formal order.

Fourthly We arrange the production.

Q6. Is it OK to print my logo on the LCD product?

A: Yes. Please inform us formally in design stage, and we will make samples with your logo for your sample test and approval. At sample approval, the mass production will follow the approved samples.

Q7: Do you offer guarantee for the products?

A: Yes, we offer 1 year warranty to our products.

Q8: How to deal with the faulty?

A: Firstly, Our products are produced in strict quality control system and the defective rate will be less than 0.2%.

Secondly, during the guarantee period, we will send new lcds with new order for small quantity. For defective batch products, we will repair them and resend them to you or we can discuss the solution including re-call according to real situation.

128x64 COG Graphic LCM Drawing

128x64 COG Graphic LCM Real Product Demostration
