    FHD Landscape IPS TFT LCD Display 5.7 Inch 60 Pin With LVDS Interface

    Ask Lasest Price
    Brand Name : SAEF
    Model Number : SF-TO570I-8968A-N
    Certification : ISO9001 / ISO14000
    Price : Negotiable based on order lot quantity
    Payment Terms : L/C, , T/T, Western Union
    Supply Ability : 3000K pcs per month
    Delivery Time : 3-5 weeks
    • Product Details
    • Company Profile

    FHD Landscape IPS TFT LCD Display 5.7 Inch 60 Pin With LVDS Interface

    5.7" Inch FHD Landscape TFT LCD Touch Screen LVDS Interface 60 Pin Display


    LVDS 5.7 inch TFT, 5.7" FHD LCD Description


    SAEF TECHNOLOGY SF-TO570I-8968A-N is a 5.7 inch full TFT-LCD display with FHD 1920x1080 resolution (1920 horizontal by 1080 vertical pixels array). This model supports LVDS interface; the supply voltage (VCC) of driving LCD panel is from is 2.8V to 3.6V. Typical value is 3.3V. It can be used in embedded systems, automation, medical equipment, industrial device, security equipment which requires TFT display in high quality and colorful image.

    SF-TO570I-8968A-N is a IPS-LCD type TFT with brightness 1000 cd/m2 (typical value). the brightness can be reduced to 300 nits for some application does not need high brightness. It can be operating at temperatures from -20℃ to +70℃; its storage temperatures range from -30℃ to +80℃.

    Product:5.7" Inch FHD LVDS TFT LCDResolution:1920x1080 Pixels
    Viewing Direction:IPS All Viewing AnglesTouch Screen:Without Touch, PCAP Optional
    Cover Lens:CustomizableSurface Luminance:1000 Cd/m2 ( Customizable)
    Interface:LVDSPin Number:60 Pins
    Connection:Plugging / ZIF ( Customizable)Driver IC:HX8239
    Operating Temp.:-20℃ To +70℃Compliance:REACH & RoHS Compliant

    Quality Management

    1. Quality policy

    Provide sound quality and deliver goods on time;

    To satisfy requirements of customers with continuous improvement


    2. EHS policy

    To observe laws and regulations and to prevent and control pollution;

    To try to reduce emission and conserve and make full use of resources;

    To improve environmental protection awareness and continuously improve the environment;


    3. Measures adopted

    It will make transparent its quality policy and improve employees’ awareness on quality via training and education;

    By implementing ‘5S’ management, it will make office and production spot tidy and orderly and employees well-trained;

    It will make sure that the ISO9001 quality guarantee system cover all rounds affecting qualities of products and services before incorporating them to regulated and procedural management and control;

    Under the premise that quality is guaranteed, it will reduce production costs including reduction of costs of raw materials and improvement of production and managerial efficiency.


    Why Choose us


    1. We provide LCD Display custom solution

    Does your product have special application requirements, electrical specifications, optical specifications, touch features, or mechanical dimensions that require customized displays? SAEF can meet your custom LCD requirements.


    2. Total solutions for Touch screen and display

    Are you worried about assembling the touch screen and display screen? SAEF can provide custom and standard touch screen including Resistive and Capacitive multi-touch solutions including air & optical bonding service as well.


    3. Commitment to quality reliability

    SAEF is Qualified by ISO9001:2015 and ISO14000, meeting the RoHS, REACH and other environmental rules in global markets. We ensure quality through the manufacturing IQC,PQC and OQC management, reliability and aging testing.


    4. Long-term supply

    Under normal circumstances, the products we recommend can be supplied for more than 5 years. If there are special needs, we will make alternative plans in advance to ensure your long-term supply requirements.




    LVDS 5.7 inch TFT, 5.7" FHD LCD Drawing

    FHD Landscape IPS TFT LCD Display 5.7 Inch 60 Pin With LVDS InterfaceFHD Landscape IPS TFT LCD Display 5.7 Inch 60 Pin With LVDS Interface


    FHD Landscape IPS TFT LCD Display 5.7 Inch 60 Pin With LVDS InterfaceFHD Landscape IPS TFT LCD Display 5.7 Inch 60 Pin With LVDS Interface



    LVDS 5.7 inch TFT, 5.7" FHD LCD Product Image

    FHD Landscape IPS TFT LCD Display 5.7 Inch 60 Pin With LVDS Interface

    FHD Landscape IPS TFT LCD Display 5.7 Inch 60 Pin With LVDS InterfaceFHD Landscape IPS TFT LCD Display 5.7 Inch 60 Pin With LVDS Interface




    FACTORY AND FACILITIES


    FHD Landscape IPS TFT LCD Display 5.7 Inch 60 Pin With LVDS Interface

    FHD Landscape IPS TFT LCD Display 5.7 Inch 60 Pin With LVDS InterfaceFHD Landscape IPS TFT LCD Display 5.7 Inch 60 Pin With LVDS Interface

    FHD Landscape IPS TFT LCD Display 5.7 Inch 60 Pin With LVDS InterfaceFHD Landscape IPS TFT LCD Display 5.7 Inch 60 Pin With LVDS InterfaceFHD Landscape IPS TFT LCD Display 5.7 Inch 60 Pin With LVDS Interface

    FHD Landscape IPS TFT LCD Display 5.7 Inch 60 Pin With LVDS InterfaceFHD Landscape IPS TFT LCD Display 5.7 Inch 60 Pin With LVDS Interface

    FHD Landscape IPS TFT LCD Display 5.7 Inch 60 Pin With LVDS InterfaceFHD Landscape IPS TFT LCD Display 5.7 Inch 60 Pin With LVDS InterfaceFHD Landscape IPS TFT LCD Display 5.7 Inch 60 Pin With LVDS Interface




    Search keyword: tft 5.7", 5.7 tft lcd, 5.7" tft lcd, 5.7 inch tft lcd, tft lcd 5.7, 5.7 tft display, 5.7" tft display, 5.7 inch tft display, tft display 5.7 inch, tft display 5.7", 5.7 inch tft lcd display, 5.7" tft screen, 5.7 inch tft screen, tft screen 5.7 inch, tft screen 5.7", 5.7 inch tft lcd screen, FHD LCD, LVDS 5.7 inch, 5.7 inch IPS, 5.7 inch FHD
